Brand
AECO
SKU
SMC12 NO
Category
Process Automation
Subcategory
Magnetic Reed Sensors and Magnets
Technical Drawings
Click to enlarge
Technical drawing 1
AECO SMC12 NO - SMC-12 NO
MAGNETIC REED SWITCH
Price
Contact for Price
Request a quote for pricing and availability
Technical Specifications
| Model | SMC-12 NO |
| Weight | 65 g |
| IP Rating | IP 67 |
| Cable Type | 2x0.25 PVC |
| Part Number | SMC000019 |
| Contact Type | Standard reed |
| Connection Type | Cable 2 m |
| Housing Material | Nickelled brass |
| Temperature Limits | -25 ÷ +100 °C |
| Repeatability (%Sn) | ± 0.3 |
| Max. Switching Power | 50 W/VA |
| Max Switching Current | 500 mA |
| Contact Actuation Time | 2 mSec |
| Max. Switching Voltage | 230 Vac/dc |
| Max. Switching Frequency | 230 Hz |
| Mechanical Characteristics | M12x1 |
